This High Speed Wicket Bag Making Machines is made with a focus on engineering ingenuity, high quality production standards and international standard components to consistently achieve production at high speeds.
The Wicketer Side Seal Machine is primarily used for the high-volume manufacturing of bread bags, diaper bags, toilet paper roll bags, sanitary napkin bags and other similar products. These machines have a high amount of precision since the bags they produce are directly fed into automated filling machines.
These machines are equipped with take-up arms instead of conventional conveyors. The take-up arms stacks the bags on needles and the needles are directly kept on the automatic filling machines. These are extremely fast machines capable of meeting high production demands. The basic machine comes with the capability to work with a set of add on attachments for converting a wide range of bags with wicket punches.
Model | VELOS 630W | VELOS 800W |
Web Width Max Before Fold | 1250 | 1500 |
Web Width Min Before Fold | 410 | 410 |
Bag Width Max | 400 / 600 | 400 / 600 |
Bag Width Min | 150 | 150 |
Bag Length Max | 600 | 750 |
Bag Length Min | 200 | 200 |
Gusset Depth Max | 75 | 75 |
Gusset Depth Min | 25 | 25 |
Speed (Cycles/Min) | 300 | 250 |
Vaccum Arms | 16”(410)/ 24” (600) | 16”(410)/ 24”(600) |
Pin Stacker | 3 +1 | 3 +1 |
Connected Load Basic M/C (KW) | 25 KW | 28 KW |
Film Processing Data (Microns) | Max/Min | Max/Min |
HDPE | 50/20 | 50/20 |
LDPE/LLDPE | 60/25 | 60/25 |
CPP | 60/25 | 60/25 |
Max Film Diameter on Unwimd | 1000mm diameter | 1000mm diameter |
Technical Data | |
Unwinder | EPC |
Dancer (Unwinder) | Pneumatic |
Film Folding Device | Motorised Controlled |
Online Gusset Unit | |
Unwinder Nip | AC Motor |
Dancer | Pneumatic with contact less control with distance sensor |
Tail Feed | Servo Driven with Pneumatically operated Nip |
Wicket Hole Punches | Pneumatic with EPC |
Photocell | Mounted on Rack & Pinion |
Film Index Drive | Servo Driven |
Cranking (Dwell Time) Main Sealing Blade | Servo Driven |
Conveyor Drive | AC Motor |
Windmill Arms | Servo Driven with Adjustable top Clutch |
Pin Stacker | Servo Driven with Motorised control |
Last Pin Stack | Machine Stop System |
